Home / Products / Conference Systems / TV-65820
TV-65820
65-inch Interactive Intelligent Touch Screen
Conference Systems · 820 Series
All-in-one Interactive Flat Panel For Conference Room
Interactive Flat Panel integrates whiteboard writing, meeting interaction, minutes sharing and other functions; it shakes off the traditional complicated operation and further creates a simple, efficient and convenient paperless meeting.
Features
- High precision infrared touch technology, 3.5mm writing height, response speed less than 15ms.
- To meet the diversified demans of enterprises, the monnitor lift has built-in Android and windows dual systems, which can be switched with one click for being user friendly
- High precision touch control, arbitrary roaming, maximum support 20 pages.
- Built in camera and pickup microphone, remote video conference, remote screen sharing, writing synchronization and other functions can be realized through cloud conference.
Technical specifications
| Model | TV-65820 |
|---|---|
| Processor | Mali-G52 MP2 dual-core, Quad-Core A55 quad-core |
| System version | Android 11 |
| RAM | 4GB |
| Storage | 32GB |
| Screen type | LED LCD screen |
| Screen size | 65 inches (16:9) |
| Screen display size | 1428.48（H）×803.52（V）mm |
| Physical resolution | 3840（H）*2160（V） |
| Pixel pitch | 0.124(H)x 0.372(V)mm |
| Color gamut NTSC (Typ) | 72% |
| Response time | Typ：6.5ms Max：12ms |
| Refresh rate | 60Hz |
| Chromaticity | 1.07B (8-bit + Hi-FRC) |
| Brightness | 200-300cd/㎡ |
| Contrast | 4000：1 |
| Viewing angle | 178°(H/V) |
| Backlight lifespan | ≥50000h |
| Audio channel | 2.0 |
| Speaker | 2×15W@ 8Ω |
| Camera pixel | 48 million-8000x6000@5fps |
| Number of camera | 1 |
| Camera field angle | D：80°H：75° V：50° |
| Microphone pickup distance | ≥8m |
| Number of microphone | 8 |
| Input port | TYPE-C*2；HDMI*1；TOUCH*1；USB3.0*2；HDMI2 IN*1；HDMI1 IN*1；RJ45 IN*1；AUDIOIN*1；VGAIN*1；DPIN*1； |
| Output port | OPTICAL OUT*1；USB2.0*1；TOUCH*1；USB3.0*2；WIFI*4；HDMI OUT*1；RJ45 OUT*1；LINE OUT*1 |
| Communication port | RS232*1 |
| Touch embedding method | Built-in integrated, non-external design |
| Touch sensing technology | Infrared recognition touch technology: PC: 20 points / Android: 10 points |
| Writing method | Fingers, stylus or non-transparent objects larger than 5mm in diameter (multi-touch 8mm) |
| Writing height | 2.5mm |
| Screen surface hardness | 7H |
| Output coordinate | 32767(W)*32767(D) |
| WiFi | 802.11a/b/g/n/ac/ax+Bluetooth5.0, working frequency: 2.4GHz/5GHz, working distance: 12m |
| Power supply | 100-240V~50/60Hz input |
| Standard power consumption | 180W |
| Standby power consumption | ≤0.5W |
| Working temperature | 0℃～40℃ |
| Working humidity | ≤80%RH |
| Overall size (L×W×T) | 1493mm*87.92mm*923.8MM |
| Package size (L×T×H) | 1597*198*1025mm |
| Weight | Net weight: 41.5±1kg Gross weight: 51.5±1kg |
