TS-86156X

Conference Systems · Paperless Conference

The paperless lifter, taking the intelligent terminal as the application concept, uses intelligent control technology and adopts the original guide rail design to automatically complete actions such as power-on, LCD screen raising, and elevation angle adjustment with one key. It is user-friendly and space-saving, making the desktop neat and beautiful. In addition, it is characterized by anti-theft, dust-proof and other functions. It can be widely used in conference rooms, office hotels, teaching studios and other occasions to meet the needs of system extension and automation. It is an ideal assistant for your office and teaching work.

Feature：

Features

• The integrated design of the touch ultra-thin high-definition display screen and the lifter, no exposed connecting wires, no connection backplane, and no exposed screws.
• Integrated lifter with microphone; the microphone supports automatic straightening function, when the mic pole is bent, it can be automatically straightened to avoid damage to the mic pole.
• Using all-aluminum structure, high-quality aluminum material and CNC engraving processing, the display frame and cabinet are made of aluminum alloy, making the device as a whole light and neat.
• The surface of the device is anodized with bright color.
• The device panel is only 3mm thick and 80mm wide, taking up little space.
• The touch panel is made of 1mm thick acrylic plate, with four touch buttons: Up, Down, Pause and Power.
• Adopt steel synchronous pulley and high-precision linear guide rail, and use AC deceleration motor as driving power to realize lifting operation, stable and quieter.
• Adopt a 15.6-inch high color gamut ultra-thin LCD touch screen with a resolution of 1920*1080P, and the display effect is clear and bright.
• The rear screen is an 11.6-inch LCD screen, which is used as an electronic nameplate
• With an 8-megapixel camera, it can be used to collect and identify personnel information in meetings.
• The panel supports up to 15W wireless fast charging.
• With HDMI and VGA two-channel signal inputs, when there is signal input, the display will automatically identify the signal, when there is no signal input, the display will automatically enter the power saving mode.
• Automatically detect the power-on status of the device, support one-key boot to raise the display, long press for 5 seconds to turn off and lower the display.
• Centralized control can be realized through the central control software; it can also be controlled via the host computer; all indoor equipment can be lifted and turned on and off with one key.
• The built-in loop-through output power socket can supply power to the terminal and reduce the wiring of the terminal power socket, making the wiring of the project site more neat and tidy.
• With dual 3.0 USB ports, the panel supports BC1.2 10W fast charging, and can be connected to a U disk for file browsing or file uploading.
