HD video terminal NT90MB (Specification B-AZ8 )

Conference Systems · HD Video Conference System

The new 4K split-type high-definition video conferencing terminal supports

H.265 technology, can achieve ultra-high-definition 4K60 effect with ultra-low

bandwidth, integrates rich audio and video interfaces, and is suitable for

various small and medium-sized meeting places.

Features

• Employs a split-type architecture with a built-in hardware video processing unit. It utilizes a
• dual-operating system design, combining domestically developed embedded Linux and Android 12, supporting switching between the two systems.
• Supports ITU-T H.323 and
• SIP standard protocols, offering excellent compatibility; supports H.239 and
• BFCP dual-stream protocols, with both main and auxiliary streams capable of
• 4K60 resolution; both main and auxiliary screens can output 4K60 resolution
• signals.
• Supports call bandwidth
• from 64Kbps to 8Mbps; supports CIF, 4CIF, 720P, 1080P, and 4K video
• resolutions.
• Supports high-definition
• video signal input of 1280×720@60fps/50fps/30fps/25fps,
• 1920×1080@60fps/50fps/30fps/25fps, and 3840×2160@60fps/50fps/30fps.
• Supports high-definition
• video signal output of 1024×768@60fps, 1280×720@60fps, 1920×1080@60fps/30fps,
• and 3840×2160@60fps/30fps.
• Supports H.261, H.263,
• H.263+, H.264, H.264 HP, and H.265 video codec protocols; supports G.711,
